ACF Shower Filter Cartridge

  • Material: PP melt-blown(inner) + Activated Carbon Fiber (media) + PP melt-blown(outer)

  • Size: 43 × 15 × 86 mm (Outer diameter × Inner diameter × Height)

  • Filtration Accuracy: 5–10 microns (customizable)

  • Recommended Flow Rate: 4–8 L/min

Category:

PP + ACF Shower Filter Cartridge Replacement for Weddell Duo

This PP+ ACF shower filter replacement cartridge combines PP and Activated Carbon Fiber in a compact cylindrical design. It is compatible with the Weddell Duo shower filter and is one of the two cartridges used in this replacement configuration.

The cartridge measures Ø43 × 90 mm (Ø1.69″ × 3.54″) and weighs approximately 1.12 oz (32 g) per piece. The PP and ACF combination provides particulate filtration and chlorine reduction in a compact cartridge designed for shower filtration applications.

ACF Shower Filter Cartridge Features and Benefits

  • High-efficiency filtration – The activated carbon fiber layer efficiently adsorbs chlorine, residual chemicals, and organic contaminants.

  • Improved water quality – Reduces unpleasant odors and improves water taste for a more comfortable shower.

  • Gentle on skin and hair – Prevents dryness and irritation by filtering out harmful substances commonly found in tap water.

  • Durable construction – The PP melt-blown outer layer provides strong structural support and ensures long-lasting performance.

  • Easy to install and replace – Designed for quick installation in most standard shower heads without special tools.

PP + Activated Carbon Fiber Filter Media

This cartridge combines PP filter media with Activated Carbon Fiber.

The PP component provides particulate filtration and helps reduce sediment and other suspended particles. The Activated Carbon Fiber provides chlorine reduction and contributes to the overall filtration performance.

The combination of the two media provides a multi-media filtration structure within a compact shower filter cartridge.

Actual filtration performance depends on the filter media, cartridge structure, water quality, flow rate, and operating conditions.

Two-Cartridge Replacement Configuration

This PP + ACF cartridge is used together with a separate Activated Carbon Fiber shower filter replacement cartridge.

Both cartridges have the same external dimensions and are designed for the same compatible shower filter. Their filter media, however, are different.

The matching ACF cartridge uses Activated Carbon Fiber as its primary filter media. It provides a chlorine removal rate of ≥70%, a flow rate of 2.8 GPM, and a rated service life of up to 8,000 gallons under the specified testing conditions.

See our Activated Carbon Fiber Shower Filter Replacement Cartridge for the complete specifications of the matching cartridge.

The two-cartridge configuration allows different filter media to be used within the same shower filter replacement system.

composite ACF shower filter cartridge

Product Specifications

Item Specification
Product Type Shower Filter Replacement Cartridge
Filter Media PP cotton + Activated Carbon Fiber
Dimensions Ø43 × 90 mm (Ø1.69″ × 3.54″)
Unit Weight Approx. 1.12 oz (32 g)
Flow Rate 2.8 GPM
Service Life Up to 8,000 gallons
Chlorine Removal Rate ≥70%
Standard / Performance NSF/ANSI 42, NSF/ANSI 177
MOQ 1,000 pcs
Lead Time Approx. 10 days
Customization Available
OEM / ODM Available

Application

This ACF shower filter cartridge is suitable for various types of shower heads in homes, hotels, gyms, and spas. It ensures a cleaner, more pleasant shower by reducing residual chlorine and impurities, providing comfort for sensitive skin, and maintaining healthy hair.

Why Choose PP + ACF?

Combining PP and ACF allows different filtration functions to be incorporated into one compact cartridge.

The PP media is used for particulate filtration, while the ACF media provides chlorine reduction. This makes the cartridge suitable for shower filter applications where both particulate and chlorine reduction are required.

The final cartridge structure can be adjusted according to the required filtration performance, flow rate, dimensions, and application conditions.

Request a Quote

If you need a PP + ACF shower filter cartridge compatible with an existing shower filter, send us your cartridge dimensions, sample, drawing, or product specifications.

We support customized filter media, cartridge structures, OEM production, and private-label packaging.

Contact us for pricing, samples, and customization options.
